pr3dict 33 Posted February 7, 2020 Share Posted February 7, 2020 Playback reporting plugin says direct stream... which one is right and how do I check? I’m using an nvidia shield. Link to comment Share on other sites More sharing options...
Happy2Play 8351 Posted February 7, 2020 Share Posted February 7, 2020 @@TeamB Can't remember if you covered this or not. But I suspect this belongs in Plugin section. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 @@TeamB Can't remember if you covered this or not. But I suspect this belongs in Plugin section. I do remember there being a post about why this happens but I couldn't find it. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 So I found the thread but his TeamB's posts are missing from it... https://emby.media/community/index.php?/topic/76358-playback-reporting/?hl=%2Bplayback+%2Breporting ^^^ If I'm reading the one sided conversation correctly it seems that emby may actually be changing the file and streaming it vs actually direct playing it. Does this sound right? @@TeamBCan't remember if you covered this or not.But I suspect this belongs in Plugin section. Link to comment Share on other sites More sharing options...
Happy2Play 8351 Posted February 7, 2020 Share Posted February 7, 2020 (edited) So I found the thread but his TeamB's posts are missing from it... https://emby.media/community/index.php?/topic/76358-playback-reporting/?hl=%2Bplayback+%2Breporting ^^^ If I'm reading the one sided conversation correctly it seems that emby may actually be changing the file and streaming it vs actually direct playing it. Does this sound right? If the client does not have direct access to the files system, Emby will stream the media instead of direct playing, but still reports Direct Play. Emby does not report Direct Play if the audio is being converted, it reports Direct Stream even though it is technically partial Transcode. Emby only reports Transcode if video need converting. Edited February 7, 2020 by Happy2Play Link to comment Share on other sites More sharing options...
TeamB 2356 Posted February 7, 2020 Share Posted February 7, 2020 Direct Play is the client is directly playing the file from disk or network share Direct Stream is the client is playing over HTTP and the server just readying and sending the file Trans-code is the client playing over HTTP and the server trans-coding either the video or audio to a new format Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 Yeah that makes sense why I’m getting the skipping trying to stream through the Emby app... I’m using VLC on the shield right now and it’s perfectly fine. Why would emby think the shield doesn’t have direct access but I’m having no problem with VLC hit the same network share? Link to comment Share on other sites More sharing options...
Happy2Play 8351 Posted February 7, 2020 Share Posted February 7, 2020 Direct Play is the client is directly playing the file from disk or network share Direct Stream is the client is playing over HTTP and the server just readying and sending the file Trans-code is the client playing over HTTP and the server trans-coding either the video or audio to a new format Not to hijack this topic, but my Roku Direct Plays my media and the Dashboard shows that, but Playback Reporting shows DirectStream. I can shutdown server and media still continues to play. Link to comment Share on other sites More sharing options...
Happy2Play 8351 Posted February 7, 2020 Share Posted February 7, 2020 Yeah that makes sense why I’m getting the skipping trying to stream through the Emby app... I’m using VLC on the shield right now and it’s perfectly fine. Why would emby think the shield doesn’t have direct access but I’m having no problem with VLC hit the same network share? It is hard to say but you would probably have to go over your Library folder setup. My Windows setup is server and data on same machine. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 Not to hijack this topic, but my Roku Direct Plays my media and the Dashboard shows that, but Playback Reporting shows DirectStream. I can shutdown server and media still continues to play. To TeamB's point I can see the http streams in the server log... Do you see the same in your log? Also It is hard to say haha. It's weird though because anything outside of the house can directplay fine through emby. All the devices inside the same subnet however, do not. They all directstream (as per playback reporting) Link to comment Share on other sites More sharing options...
TeamB 2356 Posted February 7, 2020 Share Posted February 7, 2020 yeah look in the server logs, that will show you the stream url the client is using. Link to comment Share on other sites More sharing options...
speechles 1929 Posted February 7, 2020 Share Posted February 7, 2020 (edited) Direct Play is the client is directly playing the file from disk or network share Direct Stream is the client is playing over HTTP and the server just readying and sending the file Trans-code is the client playing over HTTP and the server trans-coding either the video or audio to a new format That is in relation to the file. For streams it is a bit different language. In relation to the stream: (stats for nerds in apps / dashboard active devices) Direct Play = unmodified file (same exact container and codecs) streamed via Emby in order to maintain resume points/bookmarks. Direct Stream = when only the container was modified (all other streams within the new container are left untouched) and streamed via Emby Remux = when both the container and audio stream codec were modified (but not the video stream codec) and streamed via Emby Transcode = when for any reason the video stream has to be modified and streamed via Emby The difference between file and stream. Edited February 7, 2020 by speechles Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 Yeah something is up... The SMB share is perfectly fine but the shield keeps streaming instead of direct playing... Log attached. emby server log - shield not direct playing.txt Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 That is in relation to the file. For streams it is a bit different language. In relation to the stream: (stats for nerds in apps / dashboard active devices) Direct Play = unmodified file (same exact container and codecs) streamed via Emby in order to maintain resume points/bookmarks. Direct Stream = when only the container was modified (all other streams within the new container are left untouched) and streamed via Emby Remux = when both the container and audio stream codec were modified (but not the video stream codec) and streamed via Emby Transcode = when for any reason the video stream has to be modified and streamed via Emby The difference between file and stream. So this is important to understand because by making having emby "stream" the video file to the client I am getting a bottleneck/ stuttering issue with a 100mb/s file. I do not have this issue when using a player and pointing it to the storage share. How can I have emby just point to the file and let the client direct play in a traditional way? Link to comment Share on other sites More sharing options...
Happy2Play 8351 Posted February 7, 2020 Share Posted February 7, 2020 Yeah something is up... The SMB share is perfectly fine but the shield keeps streaming instead of direct playing... Log attached. Looking at other topics I would guess it would be a issue with SMB permissions, but a dev would have to comment. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 7, 2020 Author Share Posted February 7, 2020 I would normally agree but like I said, other apps connect fine. It just seems to be emby that is trying to circumvent the "direct play" even though statsfornerds and the dashboard say its directplaying it surely is not because of that stuttering issue I explained. Looking at other topics I would guess it would be a issue with SMB permissions, but a dev would have to comment. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 8, 2020 Author Share Posted February 8, 2020 I found this on accident... Do we have the same problem on the linux servers?!? This is a huge problem. @@Luke https://emby.media/community/index.php?/topic/81589-how-to-disable-direct-streaming/ Link to comment Share on other sites More sharing options...
Luke 37233 Posted February 8, 2020 Share Posted February 8, 2020 I think you're talking about video files which has nothing to do with that topic. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 8, 2020 Author Share Posted February 8, 2020 I think you're talking about video files which has nothing to do with that topic. "We can't verify the legality of your streams, therefore we run everything through your emby server in order to avoid having our apps potentially violate app store policies" This isn't referencing direct playing video files? My big issue which I'm trying to avoid is... Instead of streaming the video through the emby server I want the client to just grab it right from the file server... When I use an external player I notice this happens correctly though it then leaves the app, which I don't want. How can I have the file direct play without having to go through the server? (The reason I need this is because the server queuing up the video is becoming a bottleneck) Link to comment Share on other sites More sharing options...
Luke 37233 Posted February 8, 2020 Share Posted February 8, 2020 No that topic is about m3u tuners. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 8, 2020 Author Share Posted February 8, 2020 No that topic is about m3u tuners. Ah gotcha.... To my question is there anyway to do what I asked? Link to comment Share on other sites More sharing options...
Luke 37233 Posted February 8, 2020 Share Posted February 8, 2020 We haven't added direct network file access to the app yet. It's possible for the future though. Link to comment Share on other sites More sharing options...
pr3dict 33 Posted February 8, 2020 Author Share Posted February 8, 2020 (edited) We haven't added direct network file access to the app yet. It's possible for the future though. I mean am I correct in assuming that it is necessary as we get higher bitrate videos? Or should my server be able to handle a 100Mb/s stream without having the skipping issues that I am having? If so how can I diagnose that? Edited February 8, 2020 by pr3dict Link to comment Share on other sites More sharing options...
Luke 37233 Posted February 8, 2020 Share Posted February 8, 2020 I'm not sure i would say it's necessary. The smb protocol is based on http anyway so direct file access turns out to be almost the same thing. But yes in theory, anytime you can reduce extra layers, that's usually a good thing. Link to comment Share on other sites More sharing options...
