vdatanet 1618 Posted September 21, 2020 Posted September 21, 2020 (edited) I have some movies in 1080i format but Emby doesn't detect them as interlaced videos. This means that in devices that do not support interlaced video, such as Apple TV, they cannot play the content since instead of transcoding direct play is attempted. MediaInfo.txt Edited September 21, 2020 by vdatanet
vdatanet 1618 Posted September 21, 2020 Author Posted September 21, 2020 4 minutes ago, cayars said: Hi, What's the source of the file? Blu-ray rips, this particular example has been re-encoded, but I have some (well very few) blu-ray remux, using MakeMKV that are 1080i, but Emby does not detect them as interlaced. I don't know if they are strange blu-rays or are a result of wrong rips.
Carlo 4561 Posted September 21, 2020 Posted September 21, 2020 That's what I was getting to. It was likely encoded poorly. If you're going to re-encode something and it's interlaced, well, de-interlace it. Have you tried to edit the file and mark it as interlaced? I can't read that mediainfo output so I don't know what it says.
Happy2Play 9783 Posted September 21, 2020 Posted September 21, 2020 4 minutes ago, cayars said: I can't read that mediainfo output so I don't know what it says. Would assume a translation issue as it shows Sweep type instead of Scan type. Video ID: 1 Format: AVC Format / Info: Advanced Video Codec Profile format: High @ L4 Format settings: CABAC / 2 Ref Frames Format settings, CABAC: Yes Format settings, RefFrames: 2 frames Codec ID: V_MPEG4 / ISO / AVC Duration: 1 h 59 min Bit rate type: Variable Bit rate: 4 862 kb / s Maximum bit rate: 15.0 Mb / s Width: 1 920 pixels Height: 1,080 pixels Aspect Ratio: 16: 9 Frame rate mode: Constant Frame rate: 25,000 FPS Color space: YUV Chroma subsampling: 4: 2: 0 Bit depth: 8 bit Sweep Type: Interlaced Sweep type, storage method: Separate fields Sweep order: Top field first Bits / (pixel * frame): 0.094 Stream size: 4.05 GiB (67%) Title: www.descargaya.es Spanish Language Default: Yes Forced: Yes
Carlo 4561 Posted September 21, 2020 Posted September 21, 2020 Well that clearly shows it being interlaced. vdatanet can you drop to the command line and run a "ffmpeg -i filename" and see if it say's it's interlaced or not?
vdatanet 1618 Posted September 21, 2020 Author Posted September 21, 2020 6 minutes ago, cayars said: Well that clearly shows it being interlaced. vdatanet can you drop to the command line and run a "ffmpeg -i filename" and see if it say's it's interlaced or not? joan@embysrv:/media/movies/Saga Rocky [MicroHD][1080 px][-DTS-AC3 5.1-Castellano-Ingles+Subs]$ ffmpeg -i rocky\ 2.mkv ffmpeg version 4.2.4-1ubuntu0.1 Copyright (c) 2000-2020 the FFmpeg developers built with gcc 9 (Ubuntu 9.3.0-10ubuntu2) configuration: --prefix=/usr --extra-version=1ubuntu0.1 --toolchain=hardened --libdir=/usr/lib/x86_64-linux-gnu --incdir=/usr/include/x86_64-linux-gnu --arch=amd64 --enable-gpl --disable-stripping --enable-avresample --disable-filter=resample --enable-avisynth --enable-gnutls --enable-ladspa --enable-libaom --enable-libass --enable-libbluray --enable-libbs2b --enable-libcaca --enable-libcdio --enable-libcodec2 --enable-libflite --enable-libfontconfig --enable-libfreetype --enable-libfribidi --enable-libgme --enable-libgsm --enable-libjack --enable-libmp3lame --enable-libmysofa --enable-libopenjpeg --enable-libopenmpt --enable-libopus --enable-libpulse --enable-librsvg --enable-librubberband --enable-libshine --enable-libsnappy --enable-libsoxr --enable-libspeex --enable-libssh --enable-libtheora --enable-libtwolame --enable-libvidstab --enable-libvorbis --enable-libvpx --enable-libwavpack --enable-libwebp --enable-libx265 --enable-libxml2 --enable-libxvid --enable-libzmq --enable-libzvbi --enable-lv2 --enable-omx --enable-openal --enable-opencl --enable-opengl --enable-sdl2 --enable-libdc1394 --enable-libdrm --enable-libiec61883 --enable-nvenc --enable-chromaprint --enable-frei0r --enable-libx264 --enable-shared libavutil 56. 31.100 / 56. 31.100 libavcodec 58. 54.100 / 58. 54.100 libavformat 58. 29.100 / 58. 29.100 libavdevice 58. 8.100 / 58. 8.100 libavfilter 7. 57.100 / 7. 57.100 libavresample 4. 0. 0 / 4. 0. 0 libswscale 5. 5.100 / 5. 5.100 libswresample 3. 5.100 / 3. 5.100 libpostproc 55. 5.100 / 55. 5.100 Input #0, matroska,webm, from 'rocky 2.mkv': Metadata: title : www.descargaya.es encoder : libebml v1.2.3 + libmatroska v1.3.0 creation_time : 2012-12-19T13:57:29.000000Z Duration: 01:59:10.99, start: 0.000000, bitrate: 7283 kb/s Stream #0:0(spa): Video: h264 (High), yuv420p, 1920x1080 [SAR 1:1 DAR 16:9], 25 fps, 25 tbr, 1k tbn, 50 tbc (default) (forced) Metadata: title : www.descargaya.es Stream #0:1(spa): Audio: dts (DTS), 48000 Hz, 5.1(side), fltp, 768 kb/s (default) (forced) Metadata: title : www.descargaya.es Stream #0:2(eng): Audio: dts (DTS), 48000 Hz, 5.1(side), fltp, 1536 kb/s Metadata: title : www.descargaya.es Stream #0:3(spa): Subtitle: subrip (default) (forced) Metadata: title : www.descargaya.es Stream #0:4(spa): Subtitle: subrip Metadata: title : www.descargaya.es Stream #0:5(eng): Subtitle: subrip Metadata: title : www.descargaya.es
Carlo 4561 Posted September 21, 2020 Posted September 21, 2020 No headers in the file to indicate it's interlaced.
vdatanet 1618 Posted September 21, 2020 Author Posted September 21, 2020 Just now, cayars said: No headers in the file to indicate it's interlaced. Plex detects that content as interlaced and if device does not support interlaced video is transcoded as expected.
vdatanet 1618 Posted September 21, 2020 Author Posted September 21, 2020 Using idet filter, it seems to be progressive, but there are a lot undetermined frames, the better solution is to rip again. joan@embysrv:/media/movies/Saga Rocky [MicroHD][1080 px][-DTS-AC3 5.1-Castellano-Ingles+Subs]$ ffmpeg -filter:v idet -frames:v 360 -an -f rawvideo -y /dev/null -i rocky\ 2.mkv ffmpeg version 4.2.4-1ubuntu0.1 Copyright (c) 2000-2020 the FFmpeg developers built with gcc 9 (Ubuntu 9.3.0-10ubuntu2) configuration: --prefix=/usr --extra-version=1ubuntu0.1 --toolchain=hardened --libdir=/usr/lib/x86_64-linux-gnu --incdir=/usr/include/x86_64-linux-gnu --arch=amd64 --enable-gpl --disable-stripping --enable-avresample --disable-filter=resample --enable-avisynth --enable-gnutls --enable-ladspa --enable-libaom --enable-libass --enable-libbluray --enable-libbs2b --enable-libcaca --enable-libcdio --enable-libcodec2 --enable-libflite --enable-libfontconfig --enable-libfreetype --enable-libfribidi --enable-libgme --enable-libgsm --enable-libjack --enable-libmp3lame --enable-libmysofa --enable-libopenjpeg --enable-libopenmpt --enable-libopus --enable-libpulse --enable-librsvg --enable-librubberband --enable-libshine --enable-libsnappy --enable-libsoxr --enable-libspeex --enable-libssh --enable-libtheora --enable-libtwolame --enable-libvidstab --enable-libvorbis --enable-libvpx --enable-libwavpack --enable-libwebp --enable-libx265 --enable-libxml2 --enable-libxvid --enable-libzmq --enable-libzvbi --enable-lv2 --enable-omx --enable-openal --enable-opencl --enable-opengl --enable-sdl2 --enable-libdc1394 --enable-libdrm --enable-libiec61883 --enable-nvenc --enable-chromaprint --enable-frei0r --enable-libx264 --enable-shared libavutil 56. 31.100 / 56. 31.100 libavcodec 58. 54.100 / 58. 54.100 libavformat 58. 29.100 / 58. 29.100 libavdevice 58. 8.100 / 58. 8.100 libavfilter 7. 57.100 / 7. 57.100 libavresample 4. 0. 0 / 4. 0. 0 libswscale 5. 5.100 / 5. 5.100 libswresample 3. 5.100 / 3. 5.100 libpostproc 55. 5.100 / 55. 5.100 Input #0, matroska,webm, from 'rocky 2.mkv': Metadata: title : www.descargaya.es encoder : libebml v1.2.3 + libmatroska v1.3.0 creation_time : 2012-12-19T13:57:29.000000Z Duration: 01:59:10.99, start: 0.000000, bitrate: 7283 kb/s Stream #0:0(spa): Video: h264 (High), yuv420p, 1920x1080 [SAR 1:1 DAR 16:9], 25 fps, 25 tbr, 1k tbn, 50 tbc (default) (forced) Metadata: title : www.descargaya.es Stream #0:1(spa): Audio: dts (DTS), 48000 Hz, 5.1(side), fltp, 768 kb/s (default) (forced) Metadata: title : www.descargaya.es Stream #0:2(eng): Audio: dts (DTS), 48000 Hz, 5.1(side), fltp, 1536 kb/s Metadata: title : www.descargaya.es Stream #0:3(spa): Subtitle: subrip (default) (forced) Metadata: title : www.descargaya.es Stream #0:4(spa): Subtitle: subrip Metadata: title : www.descargaya.es Stream #0:5(eng): Subtitle: subrip Metadata: title : www.descargaya.es Stream mapping: Stream #0:0 -> #0:0 (h264 (native) -> rawvideo (native)) Press [q] to stop, [?] for help Output #0, rawvideo, to '/dev/null': Metadata: title : www.descargaya.es encoder : Lavf58.29.100 Stream #0:0(spa): Video: rawvideo (I420 / 0x30323449), yuv420p, 1920x1080 [SAR 1:1 DAR 16:9], q=2-31, 622080 kb/s, 25 fps, 25 tbn, 25 tbc (default) (forced) Metadata: title : www.descargaya.es encoder : Lavc58.54.100 rawvideo frame= 360 fps=342 q=-0.0 Lsize= 1093500kB time=00:00:14.40 bitrate=622080.0kbits/s speed=13.7x video:1093500kB audio:0kB subtitle:0kB other streams:0kB global headers:0kB muxing overhead: 0.000000% [Parsed_idet_0 @ 0x55d525ac1840] Repeated Fields: Neither: 345 Top: 9 Bottom: 7 [Parsed_idet_0 @ 0x55d525ac1840] Single frame detection: TFF: 2 BFF: 21 Progressive: 200 Undetermined: 138 [Parsed_idet_0 @ 0x55d525ac1840] Multi frame detection: TFF: 0 BFF: 91 Progressive: 266 Undetermined: 4
vdatanet 1618 Posted September 21, 2020 Author Posted September 21, 2020 With more frames, it seems progressive, the odd thing is that item is not playable on devices that does not support interlaced video: [Parsed_idet_0 @ 0x559ed4101840] Repeated Fields: Neither: 19035 Top: 445 Bottom: 521 [Parsed_idet_0 @ 0x559ed4101840] Single frame detection: TFF: 280 BFF: 1227 Progressive: 17303 Undetermined: 1191 [Parsed_idet_0 @ 0x559ed4101840] Multi frame detection: TFF: 42 BFF: 368 Progressive: 19587 Undetermined: 4
