troyhough 61 Posted January 16, 2019 Posted January 16, 2019 (edited) First off, hats off to the Emby team for bringing out the new update. Lots of work has went in to making this be as smooth of a transition/upgrade as possible! I haven't used Emby enough since the Server upgraded to 4.0.0.2 to know if this happens all the time or maybe just after/during a seek. Happens for just a second or 2 then back to normal. (Intel Graphics HD 4000, Windows 10 64-Bit) (Tested on Pixel 2 XL) Edited January 18, 2019 by troyhough
Happy2Play 9780 Posted January 16, 2019 Posted January 16, 2019 Does this only happen with hardware acceleration?
troyhough 61 Posted January 16, 2019 Author Posted January 16, 2019 (edited) It's enabled now (by default I think) but has never been in the past. I can disable and test again in the morning! Have you had a chance to figure this one out by chance? https://emby.media/community/index.php?/topic/67870-cant-direct-play-and-transcode-the-same-channel-hdhomerun/ Edited January 16, 2019 by troyhough
troyhough 61 Posted January 16, 2019 Author Posted January 16, 2019 (edited) Ok so I disabled Hardware Acceleration and couldn't get the pixelated/blurry images like I was getting above. Wow does the CPU take a pretty huge hit while transcoding with Hardware Acceleration disabled! Much more so with pre-recorded material versus Live TV. With H.A. disabled, the CPU would hit 90-100% at times with 2-3 transcoded streams (pre-recorded compressed material), while only 15-20% with 3 streams (pre-recorded compressed material) and H.A. enabled. So, for now, I will deal with the goofy image issue in exchange for the major CPU reduction of having H.A. enabled! Edited Jan 17 - I have disabled Hardware Acceleration. Couldn't stand the constant skipping/sputtering with Live TV. Performance (for me) is night & day better with H.A. disabled. (Server Version 4.0.0.2) Edited January 18, 2019 by troyhough
troyhough 61 Posted January 18, 2019 Author Posted January 18, 2019 (edited) I wanted to mention that in addition to the above issue with pre-recorded content, Live TV transcoding is not stable with Hardware Acceleration enabled for me. I get nonstop hiccups and freezes with my Intel HD Graphics 4000 setup. With H.A. disabled the sputtering/hiccups go away after about 30-60 sec. I edited my above post to include this too. Edited January 18, 2019 by troyhough
cptlores 40 Posted January 18, 2019 Posted January 18, 2019 (edited) I have the same problem, HW transcoding results in decoding artifacts. Using SW there is no artifacts. Emby Server (4.0.0.2) is on a i7-4790K (HD Graphics 4600) running Windows 7, no external GPU installed. The server computer is also not connected to any monitor, if that may be of any importance. Edited January 18, 2019 by cptlores 1
troyhough 61 Posted January 18, 2019 Author Posted January 18, 2019 I have the same problem, HW transcoding results in decoding artifacts. Using SW there is no artifacts. Emby Server (4.0.0.2) is on a i7-4790K (HD Graphics 4600) running Windows 7, no external GPU installed. The server computer is also not connected to any monitor, if that may be of any importance. Do you have Live TV setup? Can you test that too?
troyhough 61 Posted January 18, 2019 Author Posted January 18, 2019 I was browsing around and came across the thread below. Is it required to have a monitor (or HDM Dummy Plug) plugged into my on-board graphics slot to get Hardware Acceleration to work properly? I currently do not have a monitor plugged in since this machine is only used for Plex and Emby. When I need to connect to it, I VNC into it from another computer on the LAN. https://emby.media/community/index.php?/topic/68035-transcoding-hw-acceleration-not-working-properly/
Luke 42077 Posted January 18, 2019 Posted January 18, 2019 @@softworkz, i'll add you to the PM with the log files. Thanks. 1
Luke 42077 Posted January 18, 2019 Posted January 18, 2019 I have the same problem, HW transcoding results in decoding artifacts. Using SW there is no artifacts. Emby Server (4.0.0.2) is on a i7-4790K (HD Graphics 4600) running Windows 7, no external GPU installed. The server computer is also not connected to any monitor, if that may be of any importance. @@cptlores, let's look at an example. Please see how to report a media playback issue. thanks !
softworkz 5066 Posted January 19, 2019 Posted January 19, 2019 I was browsing around and came across the thread below. Is it required to have a monitor (or HDM Dummy Plug) plugged into my on-board graphics slot to get Hardware Acceleration to work properly? I currently do not have a monitor plugged in since this machine is only used for Plex and Emby. When I need to connect to it, I VNC into it from another computer on the LAN. https://emby.media/community/index.php?/topic/68035-transcoding-hw-acceleration-not-working-properly/ @@troyhough - you should definitely retry with having a monitor connected. You can also check BIOS settings regarding your onboard graphics (e.g. memory assignment). Then, you could try what happens when transcoding without scaling, I wonder whether this might be related to the scaling filter... 1
softworkz 5066 Posted January 19, 2019 Posted January 19, 2019 Also, the logs are showing a seemingly outdated driver version: 10.18.10.4885
troyhough 61 Posted January 19, 2019 Author Posted January 19, 2019 @@troyhough - you should definitely retry with having a monitor connected. You can also check BIOS settings regarding your onboard graphics (e.g. memory assignment). Then, you could try what happens when transcoding without scaling, I wonder whether this might be related to the scaling filter... I'll try it again with a monitor plugged in. Does the monitor need to be powered on at all times or can it be powered down (but plugged in). Just thinking long-term fix....
troyhough 61 Posted January 19, 2019 Author Posted January 19, 2019 Also, the logs are showing a seemingly outdated driver version: 10.18.10.4885 @@softworkz, Driver update crossed my mind too. I updated to 10.18.10.5059 on the 16th @ 133pm which was just after sending you the initial logs. I have done lots of testing since the update and noticed no improvement, unfortunately. I will try again with a monitor when i get some free time, hopefully tomorrow!
softworkz 5066 Posted January 19, 2019 Posted January 19, 2019 Another thing you could try is to disable hw decoding and use hw encoding only (which is the harder part). That won't solve the actual problem but it might get proper results at least.
troyhough 61 Posted January 20, 2019 Author Posted January 20, 2019 (edited) I did a lot of testing the last 24 hours. Tried with a monitor plugged, not plugged in. Just HW encoding enabled and the rest disabled. Results seemed to be the same no matter what I did. The same sputtering with Live TV and green pixelated images with pre-recorded content. I have disabled Hardware Acceleration for now until it's ready for prime time. I will be glad to test it at anytime, just let me know! PS: A "workaround" for Live TV sputtering (with H.A. enabled OR disbled) is simply hitting pause for 3-5 seconds after the tuned channel starts playing, then resuming. I'm not a coding guy but would think this is potentially a very easy fix for the Emby team!?!?! Edited January 20, 2019 by troyhough
troyhough 61 Posted January 20, 2019 Author Posted January 20, 2019 Can you please try what he asked? Thanks. @@Luke, did you see my post above? i did. try with monitor, check check bios, confirm onboard graphics enabled, check make sure on the latest HD Graphics driver, check disable hardware encoding and use hardware encoding only, check "try without scaling"?? not sure what this is?
troyhough 61 Posted January 20, 2019 Author Posted January 20, 2019 (edited) Also happening to me... exactly. Live TV sputter too? What are you using for a video card? Edited January 20, 2019 by troyhough
Luke 42077 Posted January 20, 2019 Posted January 20, 2019 @@Luke, did you see my post above? i did. try with monitor, check check bios, confirm onboard graphics enabled, check make sure on the latest HD Graphics driver, check disable hardware encoding and use hardware encoding only, check "try without scaling"?? not sure what this is? Thanks, sorry, I misread. 1
Luke 42077 Posted January 20, 2019 Posted January 20, 2019 Also happening to me... exactly. Hi there @@trentmsteel, let's look at an example. Please see how to report a media playback issue, and we're happy to help. Thanks !
